Corded Hammer Drill 750w DX-1285
- All-copper industrial armature and stator 850W
- Dust-proof key
- Hammer capability for drilling in concrete
- Includes dust-proof ball bearings
- Forward/reverse rotation system
- 2.5 meters cable which conforms to the VDE standard of Germany
- Lock-on system for consecutive drilling
- Lightweight ergonomic design with an antiperspirant coating
- Dimmer switch to control the speed
Hammer drill 13mm DX-1285 – Description
Hammer drill 13mm has a 850 W motor. This device is used for industrial purposes and is used for drilling holes in concrete, metal, and wood. This electric drill with its hammer capability can do drilling in concrete up to 16 mm thickness.
The key used in this keyed drill is a dimmer key that allows the user to control the drill’s rotation speed from zero to 2800 RPM.
Other features of this power drill includes the 13 mm keyed chuck system, which drill bits up to 13 mm can be attached to it.
The forward/reverse rotation system in the hammer drill improves the device’s performance and turns the hammer drill into a corded screwdriver.
The anti-wear gear used in this electric hammer drill 13mm can have the best functionality in heavy drillings, such as drilling in concrete.
This power drill being a lightweight device is an advantage so that the user does not get tired over a long time.
The lightness of this electric drill is an advantage so that the user won’t get tired in all day long operations.
The dust-proof, metal ball bearings used in the corded drill have special grease in their structure which increases the machine’s working efficiency. The lock-on system in this power drill allows the user to work with the machine continuously and perform drilling operations.
The 2.5 meters cable conforms to the German VDE standard. Overall this device is suitable for industrial drilling, and the user can easily perform drilling operations.
Hammer drill 13mm – Detailed Description
You can find some short surveys about the DX-1285 Below .
The 850 W motor used in this power drill consists of armature and stator. These armatures and stators stabilize the device’s power and they are produced by European machines which is why these components conform to European CE standard.
The collector used in electric hammer drill 13mm is made of the best alloys that increases the device’s lifetime. Resin and polyester provide added protection to the armature and stator of the device. This material creates a protective layer on the armature and stator which prevents the small particles such as gravel from hitting the armature wire and stator. In addition to this feature, it decreases the motor temperature during extended operations.
Hammer drill 13mm Ball Bearings
To increase the work efficiency and lifetime of the hammer drill 13mm, dust-proof ball bearings are used. There are anti-wear shots in the ball bearing’s structure and the special grease protects them from wear in the long-term.
Hammer drill 13mm Brush
Brush is one of the main parts of the hammer drill 13mm and motor. The oil graphite brush used in this keyed hammer drill is soft due to its oily surface and it has the slightest spark which leads to increasing the device’s lifetime.
There’s a cooling system in the internal structure of this hammer drill 13mm which consists of rotors and vents on the device’s body and causes the air to circulate in all parts of the motor. This factor increases the machine’s working efficiency in consecutive drilling.
Hammer drill 13mm Gearbox
An anti-wear gear is used in the electric hammer drill 13mm and its thickness is more than the gears of the other brands. The high-quality and pure alloy used in the structure of this gear increases the lifetime of the power drill in consecutive drillings.
The calcium-sulfonate based grease in the hammer drill 13mm is suitable for gears and ball bearings of electric tools. Calcium-based greases have a better impact on mechanical components than lithium-based greases. The greases won’t disappear inside the device due to prolonged operation.
Electric Hammer Drill 13mm Chuck
This device includes a keyed chuck system. The anti-wear shots and gears are used in the structure of this corded drill which will not be a problem in the long run. Metal, granite, wood drill bits up to 13 mm and even a hole saw can be attached to this keyed chuck system.
Hammer drill 13mm Features
The hammer drill 13mm includes some features like any other drills in the electric drill category. Below we have mentioned some of those features.
Hammer drill 13mm Cable
The soft and flexible cable of the hammer drill 13mm allows the user to have a better maneuverability.
The thread used in the structure of this cable makes the cable stronger and as a result increases the lifetime of this power tool.
There is an auxiliary handle with an antiperspirant coating, a depth gauge ruler, a pair of spare brushes, and a chuck wrench in the box of the hammer drill 13mm which are accompanied by a 15-month Danlex guarantee service.
Hammer drill 13mm – Technical data
|Drilling capacity in wood||
|Drilling capacity in steel||
|Drilling capacity in concrete||
a chuck wrench, a depth gauge ruler, a pair of spare brushes, An auxiliary handle
